Type2 Socket
Mario ev
| Weight: | |
|---|---|
| Plug Type: | |
| Current: | |
| Voltage: | |
| IP Degree: | |
| Meterial: | |
| Warranty: | |
The Type 2 32A 480V Female Socket is a premium EV charging outlet designed for both residential and commercial EV charging stations. Compliant with IEC 62196-2, this high-performance socket offers safe, fast charging with a 32A output and is built to last with IP54 protection. Its thermoplastic construction and copper alloy pins ensure optimal conductivity and reliability, even in harsh environments. Perfect for electric vehicles, it guarantees a secure and energy-efficient charging experience.
| Electrical Specification | Working Environment | ||
| Input Voltage | 100VAC | Protection degree | IP54 |
| Output voltage | 380VAC | Environment temperature | -30℃ ~ +50℃ |
| Max. output current | 32A | Relative humidity | 0-95% non-condensing |
| Charging interface type | IEC 62196-2 | Maximum altitude | <2000m |
| Input frequency | 47~63Hz | Standby power consumption | <8W |
| Cooling | Natural air cooling | ||
| Function and Accessory | Certificate | ||
| Shell Material | Thermo Plastic | CE | CCC |
| Contact Pin | Copper alloy, silver or nickel plating | FCC | |
| Fireproof grade of rubber shell | UL94 V-0 | ROHS | |
IEC 62196-2 Compliant: Fully compatible with global EV charging infrastructure, ensuring interoperability with a wide range of electric vehicles and charging stations.
Durable Construction: Made with thermoplastic and copper alloy for long-lasting durability and efficient conductivity, built to withstand frequent use.
IP54 Protection: Waterproof and dustproof, making it suitable for both indoor and outdoor installations, even in extreme conditions.
Fast Charging Support: Provides 32A current, enabling high-speed charging for reduced vehicle downtime.
Temperature Protection: Features over-temperature protection to prevent overheating and ensure safe operation during high-demand charging sessions.
Energy Efficient: Low standby power consumption (<8W), ensuring reduced energy waste when the socket is not in use.
Wide Operational Range: Functions effectively between -30℃ to +50℃, suitable for a wide variety of climates and environments.
Optimized for Fast Charging: The 32A output ensures high-speed EV charging, improving the overall user experience by reducing the time it takes to charge.
Enhanced Safety Features: Built-in over-temperature protection and natural cooling ensure the socket operates within safe limits, preventing overheating or damage.
Environmentally Friendly: With ROHS compliance, the socket is made from lead-free and eco-friendly materials, ensuring minimal environmental impact.
Global Certifications: Certified by CE, FCC, ROHS, and UL94 V-0, this socket complies with international safety standards, giving you peace of mind.
Ideal for use in electric vehicle charging stations, residential garages, public charging points, and commercial installations, this Type 2 charging socket is the perfect choice for businesses and homeowners seeking a reliable, fast, and safe charging solution for electric vehicles.
At MARIOEV, we provide tailored OEM/ODM solutions designed to meet your exact needs. Our products come with a 2-year warranty and are backed by expert after-sales support. With warehouses in Europe and North America, we offer fast and efficient global delivery to ensure your charging infrastructure is up and running in no time.
