2*22kw
Marioev
| Color: | |
|---|---|
| Size: | |
| Material: | |
| Power: | |
| Plug Type: | |
| IP Degree: | |
| Input Power: | |
| CHARGING BOX | EV CONNECTOR | CORE ADVANTAGE |
| High compatibility | Silver-plated design | TypeA+DC 6mA |
| Easy installation | Built in temperature monitoring chip | |
| Structural strength：IK 10 | Automatic remove impurities | Directional current regulation |
| Small size,Easy to transport | Good conductivity | |
| Waterproof grade：IP65 | Repair the disorder of capacitor units | |
| Certified by authorities (CSA, CE, FCC, NTC, CCC) | TPU CABLE | |
| Real-time monitor on charging temperature | Durable and anticorrosion | Full-link temperature monitoring system |
| Automatic error correction & reboot system | Easy to bend，Long service life | |
| Over- voltage protection/lightning protection | High resistance to cold /high temperature | Strong Expansibility(Bluetooth,WiFi, RFID,APP, OCPP) |
| Electrical Specification | Working Environment | ||
| Input Voltage | 1-phase 230V+-20%/ 3-phase 400V+-20% | Protection degree | IP65 |
| Input frequency | 50/60Hz | Environment temperature | -30℃ ~ +50℃ |
| Max. output power | 22kW(three phase) | Relative humidity | 3-95% non-condensing |
| Max. output current | 32A | Maximum altitude | <2000m |
| Charging interface type | En IEC 61851,EN 62196 | Certification | CE TUV |
| Installation | Wall-mount/Pole-mount | Start Mode | Plug&Play/RFID/APP |
| RCD | Typea/Type2B,30mA AC+DC mA | ||
DELIVERY TIME
•We have warehouses throughout Europe and North America.
•Samples or test orders can be delivered within 2-5 working days.
•Orders in standard products above 100pcs could be delivered within 7-15 working days.
•Orders that require customization could be produced within 20-30 working days.
CUSTOMIZED SERVICE
•We provide flexible customized services with our abundant experiences in kinds of OEM and ODM projects.
•OEM includes color, length, logo, packaging, etc.
•ODM includes product appearance design, function setting, new product development, etc.
•MOQ is depend on different customized requests.
AFTER SALE SERVICE
•The warranty of all our products is 2 year. The specific after-sale plan will be free for replacement or charging a certain maintenance cost according to the specific situations.
•However, according to the feedback from markets, we seldom have after-sale problems because strict product inspections are carried out before leaving the factory. And all of our products are certificated by top testing institutions such as CE from Europe and CSA from Canada.
